Aplikace snímačů Sensit

Sensors of temperature, humidity and flow in white goods and medical applications


Professional laundry technology, steam, hot-air and chemical sterilisers, laboratory driers, deep-freezing laboratory technology, water cure tubs for professional use such as rehabilitation, hotels or sport centres – this is only part of the applications where we can find special Sensit temperature sensors. In most cases this includes customer-made products manufactured upon requirements of manufacturers of individual pieces of equipment. Temperature sensors work here in the environment „far below zero“, namely at -90 °C, with high accuracy. Temperatures above zero are detected up to 400 °C.

Manufacturing always combines quality materials (stainless steel, temperature sensor, cable) with high-class workmanship. The result is a temperature sensor for particular application which is tested in cycle chambers and checked carefully. The outstanding feature of these sensors is their high quality and reasonable prices.

The main customers of the company Sensit include manufacturers of equipment that can be described with key-words: reliability, cleanness, wellness, health as well as food, pharmaceuticals, kitchens. The service companies are supported by sale warehouses of our business representatives within the territory of the Czech Republic, Slovakia and other countries not only inside the EU.

The temperature sensors, depicted on the following page, were developed in cooperation with the manufacturer of the particular equipment. We still innovate these temperature sensors; this innovation is based on development of the equipment, experience and responses of the customers.


IRONING MACHINES, DRIERS, WASHING MACHINES

Custom-made temperature sensors
Custom-made temperature sensors
Custom-made temperature sensors
  • Temperature range: from -30 to 200°C
  • Casing material: stainless steel 1.4301 Brass
  • Sensor type: Pt 100; Pt 1000; class B acc. to IEC 751
  • Cable: 2x 0.22 insulation silicone/FEP 2x 0.14 silicone
  • Ingress protection: IP 65 – IP 67 acc. to EN 60 529 529



DEEP-FREEZING TECHNOLOGY

Custom-made temperature sensors
Custom-made temperature sensors
Custom-made temperature sensors
Custom-made temperature sensors
Custom-made temperature sensors
Custom-made temperature sensors
  • Temperature range: from -200 to 150 °C
  • Casing material: stainless steel 1.4301
  • Sensor type: Pt 1000; class B acc. to IEC 751; Pt 100; TC type T
  • Cable: 4w; wires APFA 0.22
  • Ingress protection: IP 65 – IP 67 acc. to EN 60 529

STEAM STERILISERS IN HEALTH SERVICE

Standard products
Standard products
Standard products
  • Temperature range: from -30 to 200°C; from -30 to 105°C
  • Casing material: stainless steel 1.4301
  • Sensor type: Pt 100; class B acc. to IEC 751
  • Cable: 2w; Teflon 2x 0.14; 2w; PVC 2x 0,35
  • Ingress protection: IP 52 acc. to EN 60 529; IP 67 acc. to EN 60 529; IP 68 acc. to EN 60 529

HYDRO-MASSAGE TUBS

MICROWAVE OVENS

Custom - made temp. sensors
Custom - made temp. sensors
Custom - made temp. sensors
  • Temperature range: from -30 to 80°C
  • Casing material: stainless steel 1.4301
  • Sensor type: KTY 81-210
  • Cable: 2w; PVC 2x 0,14
  • Ingress protection: IP 65 acc. to EN 60 529



Custom-made temp. sensors
Custom-made temp. sensors
Custom-made temp. sensors
  • Temperature range: from -30 to 200°C
  • Casing material: stainless steel 1.4430
  • Sensor type: Pt 1000; class B acc. to IEC 751
  • Cable: 2w, silicone 2x 0.15
  • Ingress protection: IP 65 acc. to EN 60 529

SPECIAL APPLICATIONS IN HEALTH SERVICE

Custom-made temp. sensors
Custom-made temp. sensors
Custom-made temp. sensors
Custom-made temp. sensors
Custom-made temp. sensors
Custom-made temp. sensors
  • Teplotní rozsah: od od -200 do 150 °C
  • Materiál pouzdra: nerez 1.4301
  • Typ čidla: Pt 100, Pt 1000; tř. B dle IEC 751; TC typu T
  • Kabel: 4w; vodiče APFA 0,22
  • Krytí: IP 65 – IP 67 dle ČSN 60 529

HUMIDITY SENSORS

PTSV 110
PTSV 110
PTSV 110
PTSV 120
PTSV 120
PTSV 120
PTSV 130
PTSV 130
PTSV 130

FLOW SENSORS AND FLOW SWITCHES

SNP a SPP
SNP a SPP
SNP a SPP
